A Landed House at Seletar Hills Estate

Rheem Water Heater Rusty Replacement: Rheem Vertical 30L to 85VP30S at A Landed House at Seletar Hills Estate on 27 May 2025

A homeowner at Seletar Hills Estate contacted Homeone after noticing advanced rust on their ceiling-mounted Rheem water heater. Upon inspection, our technician confirmed a serious case of "Rheem Water Heater Rusty"—with rust visibly spreading across the tank body, pipe fittings, and outlet piping.

The condition of the water heater presented several risks. Rust streaks were evident along the base and side of the tank, clearly indicating internal corrosion had begun breaching the tank wall. Brownish-red water residue was found dripping onto the heater bracket and adjacent surfaces. The hot, cold, and drain piping were all visibly affected, with joint areas showing signs of oxidation and possible leak points.

Continued use of this Rheem Water Heater Rusty unit would eventually result in a full tank failure, leading to water damage, ceiling collapse, or worse—an electrical short circuit. The homeowner, aware of these risks, provided a new Rheem 85VP30S unit for installation and requested to retain the vertical 30L design due to space and capacity needs.

Project location
A Landed House at Seletar Hills Estate
Property type
Landed

Before

Replacement of a Rheem vertical 30L water heater to resolve heater problems end of service life.

After

The Rheem 85VP30S has been newly installed to the existing water heater system, with all connecting pipework made of stainless steel. The installation includes a new stop valve, double check valve, drain pipe, electric bonding, and 2.5mm² wire, and a submission has been filed to PUB to ensure safety and compliance with PUB regulations. Additionally, Homeone offers a 1-year warranty on this installation, complementing the manufacturer's warranty, ensuring peace of mind and reliable service.

Table of Contents

Rheem Water Heater Rusty Replacement: Rheem Vertical 30L to 85VP30S at A Landed House at Seletar Hills Estate

Old Water Heater:

Rheem Vertical 30L (Model number not visible)

Old Water Heater:

Rheem 85VP30S

Site Findings

The tank surface had deep rust trails and streaks
Fittings on hot, cold, and drain lines were corroded and brittle
Water staining under the bracket suggested slow leakage
The entire heater setup was at the end of its service life
Non-visible model number due to rust and label fading
The heater location and because of the heater capacity required two-man safety handling

Proposed Solution

Homeone carefully dismantled the failing Rheem Water Heater Rusty unit using a 2-man team for elevated access and safety. The new Rheem 85VP30S—a high-capacity, ceiling-mounted vertical model—was securely installed with corrosion-resistant fittings and updated safety measures.

We completed:

Safe removal of the heavily rusted heater and pipework
Installation of the new Rheem 85VP30S supplied by the owner
New stainless steel hot, cold, and drain pipes (within 1 metre)
Check valve, stopcock, and bonding applied for PUB compliance

Tested and recommissioned the heater safely under licensed supervision

Work Scope

Dismantling
Isolated water and power supply
Removal of Rheem Water Heater Rusty Unit
Cleared degraded pipe fittings and corroded electrical connectors
Verified wall anchoring and bracket integrity for the wall mount heater
Mounted the new Rheem 85VP30S securely
Installed stainless steel inlet/outlet pipework (≤1 metre)
Fitted PUB-approved double check valve and stopcock
Replaced power cable with 2.5mm² wiring
Bonded metal parts to earth according to CP5 Clause 413-02

Testing & Handover

Performed pressure and leak testing
Verified electrical safety and earthing continuity
Final visual inspection and site cleanup
Documentation
Filed compliance documents with PUB under licensed supervision

Conclusion

This Rheem Water Heater Rusty case in Seletar Hills Estate demonstrated how advanced corrosion in old storage water heaters can pose structural and electrical risks. With rust visible on the tank, joints, and fittings, the failing system was safely replaced with a vertical Rheem 85VP30S model under PUB-compliant conditions.

Homeone’s experienced team handled the job with safety-first execution and licensed supervision, delivering long-term reliability and peace of mind for the homeowner.

Project Location: Seletar Hills Estate

A Landed House at Seletar Hills Estate
