18 Jul 2025

450 Sin Ming Avenue

Rheem Vertical Tank Replacement: 65SVP10S To Ariston AN2 30 RS At 450 Sin Ming Avenue HDB on 21 May 2025

A homeowner at 450 Sin Ming Avenue HDB engaged Homeone to resolve a leaking issue from their Rheem 65SVP10S vertical water heater. The tank had reached the end of its service life, with visible water leakage from the tank body and corroded fittings. More importantly, the previous installation lacked several critical safety features, including an anti-vacuum valve, approved check valve, and electrical bonding.

To ensure full compliance and safety, the replacement was carried out under the supervision of a PUB Licensed Plumber. The client opted for the Ariston AN2 30 RS, which does not require an anti-vacuum valve, and the rest of the essential safety components were newly installed during the replacement.

  • Project location

    450 Sin Ming Avenue

  • Property type

    HDB

Rheem Gallon Tank Installation supervised by PUB Licensed Plumber at HDB.00

Before

Replacement of Rheem 65SVP10S to resolve heater problems end of service life.

After

The Ariston AN2 30RS has been newly installed to the existing water heater system, with all connecting pipework made of stainless steel. The installation includes a new stop valve, double check valve, drain pipe, electric bonding, and 2.5mm² wire, and a submission has been filed to PUB to ensure safety and compliance with PUB regulations. Additionally, Homeone offers a 1-year warranty on this installation, complementing the manufacturer's warranty, ensuring peace of mind and reliable service.

Project Overview

The tank had reached the end of its service life, with visible water leakage from the tank body and corroded fittings. More importantly, the previous installation lacked several critical safety features, including an anti-vacuum valve, approved check valve, and electrical bonding.

To ensure full compliance and safety, the replacement was carried out under the supervision of a PUB Licensed Plumber. The client opted for the Ariston AN2 30 RS, which does not require an anti-vacuum valve, and the rest of the essential safety components were newly installed during the replacement.

Why this replacement is needed?

The unit had reached the end of its lifespan, and repair was no longer practical. The decision was made to replace it with a new Ariston AN2 30 RS.

Before

Old storage water heater before replacement at 450 Sin Ming Avenue

Rheem Gallon Tank Installation supervised by PUB Licensed Plumber at HDB.01
Rheem 65SVP10S at end of service life.
After

New storage water heater installed with stainless steel piping

Rheem Gallon Tank Installation supervised by PUB Licensed Plumber at HDB.02
Ariston AN2 30 RS

Rheem Water Heater Phone Number

Rheem Water Heater Phone Number Singapore

⚠️ We are an independent PUB-Licensed Service Provider specialising in Rheem water heater inspection, servicing, and replacement in Singapore.

Need to speak to a Rheem specialist?

whatsapp icon white 24/7 Ask Rheem Expert

💬 Fast diagnosis by licensed professionals.

Select your issue:



⚠️ Looking for the Rheem water heater phone number in Singapore?

If you need quick assistance, advice, or support for your Rheem water heater, contacting the right phone number can help you resolve issues faster and avoid unnecessary delays.

Our Rheem Water Heater Phone Number Singapore connects you and is ready to assist with enquiries. Rheem Water Heater Phone Number at +65 6742 6770

🚨 What Happens When You Call Our Rheem Water Heater Phone Number?

When you contact us via our Rheem Water Heater Phone Number Singapore, we will:

Just whatsapp or call us directly.

🔻

Our Rheem Water Heater Phone Number: +65 6742 6770

Whatsapp Quick Enquiry: +65 8822 6770

The outcome of our work

Replacement Work Scope ⚙️

Removal of Non-Compliant Installation

  • Isolated power and water supply
  • Removed the Rheem 65SVP10S and associated corroded fittings

Installation of New Ariston AN2 30 RS

  • Secure wall mounting of the new unit
  • Connection of stainless steel inlet/outlet pipework within 1 metre
  • Installed double check valve, stop valve, and drain pipe
  • Upgraded wiring and installed electrical bonding
  • System tested for leaks, grounding, and pressure stability

Testing & Commissioning

  • Conducted leak and pressure tests
  • Verified temperature control and heater functionality
  • Final safety inspection & clearance
PUB Certificate 450 Sin Ming Avenue

Submission for PUB

Our job was completed together with the required PUB submission. This ensures all plumbing works meet PUB’s standards and comply with Public Utilities (Water Supply) Regulations — a key part of doing the job safely and correctly.

Conclusion:

This replacement project at 450 Sin Ming Avenue HDB was completed with a clear focus on safety, quality, and regulatory compliance. The outdated and leaking Rheem 65SVP10S was replaced with a modern, efficient Ariston AN2 30 RS, and all necessary fittings—including an approved check valve, stop valve, and electrical bonding—were installed.

The entire installation was conducted in accordance with PUB standards and under the direct supervision of a PUB Licensed Plumber, ensuring a safe and fully compliant setup. PUB documentation was also submitted upon completion, providing the homeowner with peace of mind and long-term reliability.
